Reliable Protection. Crystal-Clear Performance. The Clarity BoardView Series combines advanced Glue-on-Board (GOB) technology with precision pixel pitch options to deliver durable, high-quality indoor LED visuals. Designed for commercial environments such as control rooms, meeting spaces, and corporate displays, it ensures long-lasting clarity and seamless viewing.
• Glue-on-Board (GOB) Surface Protection for Enhanced Durability
• Ultra-Fine Pixel Pitch Options from P1.25 to P4 for High-Resolution Displays
• High 7000:1 Contrast Ratio for Deep Blacks and Vivid Colors
• Wide 160° Horizontal and Vertical Viewing Angle
• Ultra-High Refresh Rate of ≥3840Hz for Smooth, Flicker-Free Performance
• Full Front Maintenance Design for Easy Installation and Service
| Technical Parameters | P1.25 | P1.538 | P1.86 | P2.0 | P2.5 | P3.076 | P4.0 |
|---|---|---|---|---|---|---|---|
| Pixel Pitch | 1.25mm | 1.538mm | 1.86mm | 2mm | 2.5mm | 3.076mm | 4mm |
| Pixel Configuration | SMD1010 GOB | SMD1010 GOB | SMD1515 GOB | SMD1515 GOB | SMD2020 GOB | SMD2020 GOB | SMD2020 GOB |
| Module Resolution | 256 × 128 | 208 × 104 | 172 × 86 | 160 × 80 | 128 × 64 | 104 × 52 | 80 × 40 |
| Pixel Density (px/㎡) | 640000 dots/㎡ | 422753 dots/㎡ | 289050 dots/㎡ | 250000 dots/㎡ | 160000 dots/㎡ | 105688 dots/㎡ | 10000 dots/㎡ |
| Module Size | 320mm × 160mm | 320mm × 160mm | 320mm × 160mm | 320mm × 160mm | 320mm × 160mm | 320mm × 160mm | 320mm × 160mm |
| No. of Module / Cabinet | 2 × 3 | 2 × 3 | 2 × 3 | 2 × 3 | 2 × 3 | 2 × 3 | 2 × 3 |
| Cabinet Size | 640 × 480mm | 640 × 480mm | 640 × 480mm | 640 × 480mm | 640 × 480mm | 640 × 480mm | 640 × 480mm |
| Cabinet Area (㎡) | 0.3072 | 0.3072 | 0.3072 | 0.3072 | 0.3072 | 0.3072 | 0.3072 |
| Cabinet Resolution (px) | 512 × 384 | 416 × 312 | 344 × 258 | 320 × 240 | 256 × 192 | 208 × 156 | 160 × 120 |
| Avg Power Consumption (W/㎡) | 300W | 300W | 300W | 300W | 300W | 300W | 300W |
| Max Power Consumption (W/㎡) | 650W | 650W | 650W | 650W | 650W | 650W | 650W |
| Cabinet Material | Aluminum Die Cast | Aluminum Die Cast | Aluminum Die Cast | Aluminum Die Cast | Aluminum Die Cast | Aluminum Die Cast | Aluminum Die Cast |
| Cabinet Weight | 6.5kg | 6.5kg | 6.5kg | 6.5kg | 6.5kg | 6.5kg | 6.5kg |
| Viewing Angle | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
| Viewing Distance | 1–50m | 1.5–60m | 1.5–60m | 2–80m | 2–80m | 3–100m | 4–120m |
| Refresh Rate | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz |
| Color Processing | 16bit | 16bit | 16bit | 14–16bit | 14–16bit | 14–16bit | 14–16bit |
| Color Temperature | 5000–10000 Adjustable | 5000–10000 Adjustable | 5000–10000 Adjustable | 5000–10000 Adjustable | 5000–10000 Adjustable | 5000–10000 Adjustable | 5000–10000 Adjustable |
| Working Voltage | AC100–240V 50–60Hz | AC100–240V 50–60Hz | AC100–240V 50–60Hz | AC100–240V 50–60Hz | AC100–240V 50–60Hz | AC100–240V 50–60Hz | AC100–240V 50–60Hz |
| Brightness | 600–800 Nits | 600–800 Nits | 600–800 Nits | 600–1000 Nits | 600–1000 Nits | 600–1000 Nits | 600–1000 Nits |
| Contrast Ratio | 7000:1 | 7000:1 | 7000:1 | 7000:1 | 7000:1 | 7000:1 | 7000:1 |
| Lifetime | ≥100,000 hours | ≥100,000 hours | ≥100,000 hours | ≥100,000 hours | ≥100,000 hours | ≥100,000 hours | ≥100,000 hours |
| Working Temperature | -20℃~60℃ | -20℃~60℃ | -20℃~60℃ | -20℃~60℃ | -20℃~60℃ | -20℃~60℃ | -20℃~60℃ |
| Working Humidity | 60%~90%RH | 60%~90%RH | 60%~90%RH | 60%~90%RH | 60%~90%RH | 60%~90%RH | 60%~90%RH |
| Maintenance | Front | Front | Front | Front | Front | Front | Front |
| IP Rating | IP5X with GOB | IP5X with GOB | IP5X with GOB | IP5X with GOB | IP5X with GOB | IP5X with GOB | IP5X with GOB |
| Certification | CE, FCC, ROHS, EMC, LVD, BIS | ||||||
